WHY PRO+ 2?
Take the Deeper PRO+ 2 with you no matter the season or fi shing type.
This light and portable fi shing gadget has an outstanding scanning
range and scanning depth. Get accurate real-time data on your screen
with the Fish Deeper™ app. Plan, log and analyse your fi shing trips, and
create your own bathymetric maps. Access your data on any device.
BUILT-IN GPS
Create lake maps from the shore, dock or bank. Just cast out and reel in
to start mapping a water body. Your maps are automatically saved to
Fish Deeper™ and accessible on any device.
3 BEAM FREQUENCIES FOR ACCURACY
Cover large expanses and locate fi sh holding spots faster with the wide
angle beam. Use the mid beam to drill in on that hotspot you’ve located.
Home in on specifi c features and target species with the narrow angle
beam.
OUSTANDING DEPTH AND CASTING RANGE
Scans down to 100 m / 330 ft with accuracy and precision. It generates
its own Wi-Fi signal (no cellular data needed) to connect to your smart
device, so cast out to 100 m / 330 ft and feel confi dent there will be rock
solid connectivity.
EXCELLENT TARGET SEPARATION
With a target separation of 1 cm / 0.4” (narrow beam) and 2.4 cm / 1”
(wide and mid beams), you’ll be able to easily pinpoint target species
and track even the tiniest lure when vertical jigging.
WHY DEEPER?
We are pioneers in castable, smart sonar technology. With our fi rst
smart sonar released in 2013, we have only moved onward and upward,
constantly challenging ourselves to innovate more and do everything
better. Our sonars are superior quality, designed and made in Europe,
and with 24/7 customer care. Our anglers always come first.
WHAT’S NEW?
The same great product now upgraded and improved.
3 BEAM FREQUENCIES. Wide angle beam 47° (100 kHz), mid beam
20° (240kHz), and narrow beam 7° (675kHz). Better for ice and boat
fishing.
TOTALLY VERSATILE.
Various fi shing modes for specifi c types of
fi shing. Use for boat/kayak, shore/bank and even ice fi shing with its
traditional fl asher view. Fish in the summer or the winter, during the day
or night. One sonar fi ts all.
EASILY PORTABLE.
Wireless, small and lightweight. It’s smaller than
a tennis ball and weighs only 90 g (3.2 oz). Comfortably fi ts in a hatch,
tackle pack and even your pocket.
BATHYMETRIC MAP CREATION.
Create your own maps and
access all your scans, maps, points of interests, photos and notes on the
Fish Deeper™ app and web platform.
USER-FRIENDLY APP.
See fish, vegetation, bottom structure,
contour, hardness and consistency. Fish Deeper™ app includes water
temperature and depth, various colour palettes for viewing, optional
icons, sonar sensitivity adjustments and traditional ice fl asher.
ONLY QUALITY. Made from highly durable ABS plastic with titanium
inserts and a silicone gasket, it’s not only water proof, but weather proof,
handling temperatures as low as -20°C / -4°F.
LONGER LASTING FAST CHARGING BATTERY.
Working time up to 9 hours. Charges to 80% in just 45 minutes and to 100% in 75
minutes.
BETTER SONAR READINGS.
More crisp and clear visuals, making it easier to identify whatever you’re after.
INCREASED SCANNING DEPTH.
Scans down to 100 m / 330 ft.
Material ABS enclosure, Titanium inserts
Sonar Type 3 Frequency
Frequency (Beam cone) Narrow 675 kHz (cone angle 7°)
Medium 240 kHz (cone angle 20°)
Wide 100 kHz (cone angle 47°)
Target separation 1 cm / 0.4 in Narrow beam
2.4 cm / 1 in Medium beam
2.4 cm / 1 in Wide beam
Min - Max depth 15 cm - 100 m / 6 in - 330 ft
Scanning rate Up to 15 / second
Sonar modes Standard, Boat, Ice fishing, Onshore GPS
Temperature sensor Water surface temperature sensor in Celsius / Fahrenheit
Operating temperature -20°C to 40°C / -4F to 104F
GNSS (Global positioning systems supported) GPS, GLONASS, Galileo, BeiDou, QZSS
Operating time Up to 9 hours
Charging technology Fast charge
80% in 45 min.
100% in 75 min.
Internal battery Li-Ion, 3.7V Rechargeable, 950 mAh
Outlet adapter (not included) Input 110V/220V. Output Micro USB, 5V 2A
Connectivity Wi-Fi
Connectivity range Stable connection up to 100 m / 330 ft
Colour Black
Package content PRO+ 2 Sonar
USB wire
Neoprene pouch
Attachment bolts x2
Quick Guide
Safety Regulations
